G547E2P81U MSOP-8 配电开关芯片 深圳科瑞芯热销！
Features
90mW High-Side MOSFET
(G547E,G547F,G547G,G547H, G547M)
Available with 5 Versions of Current Limits with
Foldback
Operating Range:2.7V to 5.5V
1mS Typical Rise Time
Fast Overcurrent Response -3s (TYPICAL)
Under voltage Lockout
100A Quiescent Supply Current
1A Maximum Shutdown Supply Current
Logic Level Enable Pin, Available with
Active-High or Active-Low Version
No Reverse Current when Power Off
Deglitched Open-Drain Over-Current Flag
Output (OC )
With Output Shutdown Pull-low Resister
SOT-23-6, SOP-8, MSOP-8 and TDFN3X3-8 Packages
UL Approved_#E232223
Nemko IEC 60950-1 CB/CCA_scheme Certification
Report #67291
