微源原厂原装 LP62610 同步升压转换芯片
General Description
The LP62610 device is a synchronous boost convertor with ultra-low quiescent current. It features a true-shutoff function that disconnects the input and output during shutdown and output short-circuit conditions.The LP62610 only consumes 1uA quiescent current under light load condition and can achieve up to 75% efficiency at 20uA load. It can achieve up to 93% efficiency at 200mA load from 3.3 V to 5V conversion.
Features
◆ Up to 95% efficiency
◆ Output to Input Disconnect at Shutdown Mode
◆ Shut-down current:<0.1uA
◆ Over Output Voltage Protection
◆ Over Current Protection
◆ Over Temperature Protection
◆ Internal Compensation of Soft-start
◆ 1.2MHz fixed frequency switching
Application
◆ Tablet, MID
◆ Smart Phone
◆ Power Bank
