微源高效率芯片 LP6492F31SOF 同步降压变换器

General Description

The LP6492SOF-B is a synchronous, rectified, step-down, switch-mode converter with built-in power MOSFET.

The LP6492 offers a very compact solution that achieves a maximum of 2.4A of continuous output current.

The LP6492 has synchronous mode operation for high efficiency over the output current load range. Current-mode operation provides fast transient response and eases loop stabilization.

The LP6492 requires a minimum number of readily available standard external components. Other features include cable compensation, programmable current limit and thermal shutdown.

Features

◆ Wide 8V to 30V Continuous Operating Input Range

◆ 78mΩ/65mΩ Low RDS(ON) Internal Power MOSFET

◆ Up to 93% Efficiency

◆ Default 160kHz Switching Frequency

◆ Internal Soft Start

◆ Output Line Drop Compensation

◆ Over-Current Protection (OCP) programmable with External Resistor

◆ No Loop Compensation Required

◆ Thermal Shutdown

◆ Available in SOP-8 Package

Applications

◆ Car Charger

◆ Pre-Regulator for Linear Regulators

◆ Distributed Power Systems

◆ USB Dedicated Charging Ports (DCP)
