微源LDO稳压器 LP3983HAX5F SOT89-5封装

General Description

The LP3983HAB5F is designed for portable RF and wireless applications with demanding performance and space requirements.

The LP3983HAB5F performance is optimized for battery-powered systems to deliver ultra-low noise and low quiescent current. Regulator ground current increases only slightly in dropout, further prolonging the battery life.

LP3983HAB5F also works with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications, critical in hand-held wireless devices.

The LP3983H consumes less than 0.1μA in shutdown mode and has fast turn-on time less than 50μs.

The other features include ultra-low dropout voltage, high feedback accuracy, current limiting protection, and high ripple rejection ratio.

It is available in the 5-lead of SOT23-5 andSOT89-5 packages.

Features
◆ Ultra-Low-Noise for RF Application
◆ 2.5V- 6V Input Voltage Range
◆ Low Dropout : 200mV @ 300mA
◆ High PSSR:-70dB at 1KHz
◆ < 0.01uA Standby Current When Shutdown
◆ TTL-Logic-Controlled Shutdown Input
◆ Custom Voltage Available
◆ Ultra-Fast Response in Line/Load Transient
◆ Quick Start-Up (Typically 50us)
◆ Current Limiting and Thermal Shutdown Protection

Applications

◆ Portable Media Players/MP3 players

◆ Cellular and Smart mobile phone

◆ LCD/ DSC Sensor

◆ Wireless Card
