型号: | LP3987H-18B5F |
厂 商: | |
品牌/商标: | 微源半导体 |
产品类别: | 集成电路/IC- DC/DC电源芯片 |
联系人: | 颜先生/William |
电话: | 0755-82170220,21001680 |
LP3987H-18B5F 微源600mA LDO稳压器
General Description
The LP3987H is designed for portable RF and wireless applications with demanding performance and space requirements. The LP3987H performance is optimized for battery-powered systems to deliver ultra low noise and low quiescent current. Regulator ground current increases only slightly in dropout, further prolonging the battery life.The LP3987H also works with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications, critical in hand-held wireless devices.The LP3987H consumes less than 0.01?A in shutdown mode and has fast turn-on time less than 20?s. The other features include ultra low dropout voltage, high output accuracy, current limiting protection, and high ripple rejection ratio. It is available in the 5-lead of SOT23-5 packages.
Applications
◆ Portable Media Players/MP3 players
◆ Cellular and Smart mobile phone
◆ Sensor Module, RF Module
