PT2315E 普诚音频处理器芯片 深圳原装现货
DESCRIPTION
The PT2315E is an audio processor designed forversatile application, includes master volume controlwith low frequency loudness compensation, speakeroutput attenuator and tone control. It is a good solutionfor the home audio signal processing.
Due to the high reliability requirement from the audiobusiness, the PT2315E improves both audioperformances and input surge current capability, thesecauses the PT2315E is the best solution for thecost-effective audio systems.
FEATURES
● Master volume from 0 dB to -78.75dB in 1.25dB/step
● Speaker attenuator for balance, range from 0dB to -38.75dB in 1.25dB/step
● Each channel output can be muted individually.
● Low frequency loudness compensation
● Bass and Treble control, range from -14dB to +14dB in 2dB/step
● Wide operation range (VDD=4V to 10V)
● Low harmonic distortion, low noise
● Improved and replace PT2315 and PT2315A
APPLICATIONS
● Flat Panel TV
● Home Audio System
● Powered Speaker System
