DESCRIPTION
PT2509 is a full-bridge driver with build-in drivingpattern for the swing head motor application.It integrates the over temperature protection, shortcircuit protection, and under voltage protection. Withone EN control pin, the PT2509 will deliver 50HzPWM waveform to drive the AC synchronous motor.Besides the 50Hz pattern, a clock signal can alsofeed to EN pin to operate with required frequency.PT2509 with package in SOP8.
FEATURES
●Full-bridge driver with fixed pattern for Asynchronous motor
● Short Circuit Protection (SCP)
● Over Temperature Protection (OTP)
● Under Voltage Lock-Out protection (UVLO)
● Sinewave or trapezoid-like driving waveform
● 40Hz to 100Hz adjustable driving frequency
APPLICATIONS
● Fan with swing head motor
