长晶 CJ6211A15N 正极稳压器 SOT-23封装

INTRODUCTION

The CJ6211 series are a group of positive voltage regulators manufactured by CMOS technologies with high ripple rejection, ultra low noise, low power consumption and low dropout voltage, which can prolong battery life in portable electronics. The CJ6211 series work with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications. The CJ6211 series consume less than 0.1μA in shutdown mode and have fast turn-on time less than 50μs.The series are very suitable for the battery-powered equipments, such as RF applicationsand other systems requiring a quiet voltage source.

Features

● High Ripple Rejection: 80dB@1kHz

● Low Dropout Voltage: 55mV@100mA

● Low Quiescent Current: 50μA

● Excellent Line and Load Transient Response

● Operating Voltage Range: 1.8V ~ 6.0V

● Output Voltage Range: 0.8V ~ 5.0V

● High Accuracy: ±2% (Typ.)

● Output Noise Voltage: 40 μVRMS (VOUT = 3.3V, 10Hz ~ 100kHz)

● Built-in Current Limiter, Short-Circuit Protection

● TTL- Logic-Controlled Shutdown Input

Applications

● Cellular and Smart Phones

● Laptop, Palmtops and PDA

● Digital Still and Video Cameras

● Portable Audio Video Equipments

● Radio control systems

● Battery-Powered Equipments
