| 型号： | TD1519A |
| 厂 商： | |
| 品牌/商标: | TECHCODE/泰德 |
| 产品类别： | 集成电路/IC- AC/DC电源芯片 |
| 联系人: | 颜先生/William |
| 电话： | 0755-82170220,21001680 |
深圳供应 TD1519A 泰德同步整流降压变换器
General Description
The TD1519A is a monolithic synchronous buckregulator. The device integrates two 90mΩ MOSFETs, and provides 2A of continuous load currentover a wide input voltage of 4.75V to 32V. Currentmode control provides fast transient responseand cycle-by-cycle current limit.An adjustable soft-start prevents inrush current atturn-on, and in shutdown mode the supply currentdrops to 1μA.This device, availablein an SOP8-PP package,provides a very compact solution with minimal externalcomponents.
