产品详情

VIA威盛原装进口电源方案VL160--带USB C型数据交换机，深圳科瑞芯现货热销

产品型号：VL160

包装：3000pcs/盘

封装：QFN-28

产品特性：

•  4:2 10Gbps USB Type-C Data Switch

•  Support up to 10Gbps

•  2 Differential Channel, 2:1 MUX/DeMUX

•  Compatible with 10Gbps USB3.1 Gen2

•  Low power consumption with 0.5mA active and 4uW shutdown

•  High DC common mode voltage supporting to 2.2V

•  28 pins QFN 3.5 x 4.5mm package

•  ESD > 4KV, CDM > 500V

•  Lead(Pb)-Free and RoHS compliant

•  MUX

– Insertion loss: 1.5dB @ 5GHz typ.

– Return loss: 15dB @ 5GHz typ.

– Crosstalk Isolation: 30dB @ 5GHz typ.

– Off Isolation: 15dB @ 5GHz typ.

•  CC Functional

– Define Role: Device (UFP, default) or Host (DFP)

– Plug Orientation: Flipped or Not, and control Switch SEL

– (UFP) Current Capability Detect: 3.0A, 1.5A, or 0.9A

– (UFP) Rd

– (DFP) Rp (or Ip), Vconn SW if Ra

– (DFP) VBUS_EN to turn on Host VBUS SW

•  Vconn

– 5V, max Power is 1W, max current is 250mA

– Over current protection

产品实拍图：
