                台湾威盛（VIA）电池充电支持的USB电源开关方案VP201

产品型号：VP201

封装：DFN-8

包装：3000pcs/盘（拆盘需申请）

产品应用：通用墙壁充电适配器、外部备用电池、汽车点烟器充电器、充电站等... ...

产品特点：

● 95mΩ(Typ.) MOSFET Power Switch

● Compatible with USB 2.0 and 3.0 power switch requirement

● Supports charging for most available Apple devices, BC 1.2 compliant devices and Samsung Devices

● Meets Chinese Telecommunication Industrial Standard YD/T 1591-2009

● Meets Battery Charging Specification BC 1.2 for DCP

● Automatic selection of D+/D- mode for an attached device

● Adjustable current limit up to 2.6A (Typ.)

● Thermal and Short-Circuit protection

● Under-Voltage Lock Out protection

● OUT node discharge support

● Reverse current blocking

● Ambient operating temperature: -20C to 85C

● Available in 8-pin ESOP package

● Lead(Pb)-Free and RoHS compliant
