产品详情

ETA钰泰36V/3.5A高压大电流异步降压稳压器ETA2822，ETA2822E8A深

圳科瑞芯现货供应

The ETA2822is atotal solutionIC specifically for high voltage USB charging

applications. It includes a wide input range, highefficiency, and high frequency DC-to-

DC step-down switching regulatorthat is capable of delivering up to 3.1A of output

current. The DC-DC in ETA2822 is a current mode converter with a fixedfrequency that

is externally adjustable. There is also a cable resistance compensation feature that

allows users to adjust the output voltage to compensate for the voltage drop due to

cable resistance.

产品特点：

•  Wide Input Operating Range from 4V to 36V

•  Standoff Input Voltage: 42V

•  High Efficiency at 12V In 5V Out: Up to 91%:

•  High Efficiency PFM mode at light load

•  Capable of Delivering 3.1A output current

•  Cable resistance compensation

•  Adjustable Switching frequency

•  Adjustable Output current limit

•  Current Mode control

•  Logic Control Shutdown

•  Thermal shutdown and UVLO
