4通道串行输入电机驱动器方案G2036，科瑞芯热销中

产品型号：G2036

封装：WLCSP

G2036产品特点：

• Build-in two micro-steps drive mode is possible from 2-2 phase / 1-2 phase (100% / 70%) stepper drive to maximum 1024 resolution micro-steps.

• Low on-resistance (1.2, sum of on-resistance of upside and bottom side)

• Output current：Iout<=0.8A(max.) for each channel

• Build-in thermal shutdown (TSD, 150°C)

• All power supply systems (VCC, VM12, VM34) can be set up with an independent power supply

• Power save mode corresponds by I2C setup

• PI (photo interrupter drive) 2 channel built-in.

• PR Comparator 2 channel built-in.

• Built in 2channel 12bits ADC with 2KHz sampling rate

• Small WLCSP(66-36 ball Pitch 0.4mm)

• Build-in POR (power on reset).

• 2-wire (I2C-compatible), 1.8V serial interface

• 2.5V~3.6V VCC Operation voltage.

• 2.5V~3.6V VM Operation voltage.
