科瑞芯40V电子保险丝G5289，保证原装，假一罚十

产品型号：G5289

封装：DFN-10

包装：3000pcs/盘

产品特点：

• 4.5V to 40V Input Range

• Continuous current (typ): 7A

• N-channel on-resistance (typ): 10mΩ

• En/Fault functions

• Programmable overvoltage lockout

• Internal undervoltage lockout

• Short-circuit limit

• Programmable overload current limit up to 9A

• Controlled output voltage ramp

• Programmable soft start function

• Thermal latch (typ): 165°C

• Operating junction temp. - 40°C to 125°C

• Available in DFN10 (3x3 mm) package
