ETA（钰泰） ETA1062V33S2F SOT23-5 高效的同步升压变换器

1μA Ultra low IQ 1A Synchronous Boost in SOT23-6
ETA1062 is a high efficiency synchronous step-up converter with ultra-low quiescent current down to 1μA. It is capable of delivering at least 2W of power from a low voltage source, i.e. 0.4A at 5V output. It also features a true-shutoff function that disconnects the input from output, during shutdown and output short-circuit conditions.

Features
Ultra low IQ when No Switching :1uA
Output Disconnect
Short-circuit Protection
2W Output Power when Vout=5V, Vin=3.3V
Output to Input Reversed Current Protection
Up to 94% Efficiency
Internal Synchronous Rectifier
Current Mode control
Logic Control Shutdown and Thermal shutdown
SOT23-6 Package
