钰泰 ETA8015 DFN-10 电池充电管理芯片

DESCRIPTION
The ETA8015 is a high-ficiency. DC-to-DC step-down
swithing regulators, capable of delivering up to 3A of
output current. The device operates from an input voltage
range of 3.6V to 5.5V and provides an output voltage from
0.8V to VIN, making the ETA8O15 ideal for low voltage power
conversions. External programmable frequency and
compensation network of the E TA8015 enable system
designers to make trade off according to different
requirements such as board space， output transient
response and efficiency. Internal soft-start control
circuitry reduces inrush current. Short -circuit and
thermal-overload protection improves design reliability.
ETA8D15 is housed in a DFN-1O Package
