ETA2894Q3Y QFN3x4-24 40V/3A 高效同步降压转换器

40V/3A, 9μA IQ, High Efficiency Synchronous Step-Down Converter
The ETA2894 is a high-efficiency and high frequency DC-to-DC step-down switching regulator, capable of delivering up to 3A of output current. The device operates with input voltage from 3.6V to 40V, making the ETA2894 ideal for wide input voltage range power conversion.

Features
Wide Input voltage range 3.6V-40V
Ultra No load IQ 9uA
Capable of Delivering 3A output
Current mode Control
Programmable switching frequency
High Efficiency PFM mode at light load
High Efficiency Synchronous operation
Low Rdson Internal power FETs
Thermal Shutdown and UVLO protection
Available in QFN3x4-24 Package
