General Description

The AT1527 high-efficiency, DC/DC buck converter delivers up to 3A of output current. The device operates from an input voltage of 2.5V to 6V and provides an output voltage from 0.8V to VIN, making the AT1527 ideal for on-board post-regulation applications.

The AT1527 operate at a fixed frequency of 1MHz with an efficiency of up to 94%. The high operating frequency minimizes the size of external components. Internal soft-start control circuitry reduces inrush current. Short-circuit and thermal-overload protections improve design reliability.

The AT1527 are available in a space-saving 8-pin SO package.

Features

■ Ceramic Input and Output Capacitors

■ Efficiency Up to 94%

■ Operate from 2.5V to 6V supply

■ Adjustable Output from 0.8V to VIN

■ Internal Soft-Start

■ Short-Circuit and Thermal-Overload Protection

■ Input Over Voltage Protection

■ RoHS Compliant

Applications

■ ASIC/DSP/μP/FPGA Core and I/O Voltages

■ Set-Top Boxes

■ Cellular Base Stations

■ Networking and Telecommunications
