Features

■ SMBus interface

■ Programmable Trip Point (TOS) and Hysteresis (THYST)

■ Separate open-drain output pin operates as interrupt or comparator at output

■ Register readback capability

■ Power up defaults permit stand-alone operation as thermostat

■ Shutdown mode to minimize power consumption

■ Up to 8 G751s can be connected to a single bus

Key Specifications

■ Supply Voltage 3.0V to 5.5V

■ Supply Current operating 280μA (typ)

1mA (max)

shutdown 2μA(typ)

■ Temperature Accuracy

-25°C to 100°C ±2°C (max)

-55°C to 125°C ±3°C (max)

Applications

■ System Thermal Management

■ Personal Computers

■ Office Electronics

■ Electronic Test Equipment
