General description

G2260 is a low differential linear regulator with ultra-low current consumption and high output voltage accuracy. The power supply current at no load is generally 1 μ A. Built in low conductivity resistor, achieving low voltage drop and high output current. The minimum output current limit is set to 250mA. G2260 adopts a minimum of 0.1μ The I/O capacitor of F is packaged in space saving SOT-23-3.

Feature

● The no-load power supply current is generally 1 μ A

● Guaranteed 250mA output current (3.0V output)

● @vin≥vout+1v

● Input voltage range: 2.1V~6.5V

● Output voltage: 1.5V~5.0V

● Voltage drop voltage: 150mV @100mA load

● Built in overcurrent protection

● Stable and low-cost ceramic capacitors

Application

● Power supply for battery powered equipment

● Mobile phones and other portable devices
