深圳常备 SC8002AQDKR 南芯高效降压控制器

Description

The SC8002AQDKR is a synchronous buck controller with a wide input voltage from 4.6V to 36V. It can be configured as dual-outputs or single output. SC8002AQDKR regulates the output voltage at a fixed 5V or customized voltage by setting the divider resistor. It also provides high accurate output current limit. The SC8002AQDKR enters Constant Current (CC) Mode in case any of the two output channels reaches the setting current limit. The total output power can be programmed by a resistor, which makes it easy for constant power control.

TheS C8002AQDKR adopts frequency setting and operating modes selection for PWM and PFM mode. With minimum external components, maximum functions can be achieved for user’s different applications.

The SC8002 also supports full protections including under voltage protection, over voltage protection, short current protection and auto-restart, over temperature protection.

The SC8002 adopts 20 pin QFN 3 x 3 package.

Applications

● Car Charger

● Multi-Ports Wall Charger

● Hub

● Industrial applications
