微源 LP3982-18JS5 低噪音LDO稳压器

General Description

The The LP3982 is designed for portable RF and wireless applications with demanding performance and space requirements. The LP3982 performance is optimized for battery-powered systems to deliver ultra low noise and low quiescent current. A noise bypass pin is available for further reduction of output noise. Regulator ground current increases only slightly in dropout, further prolonging the battery life. The LP3982 also works with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications, critical in hand-held wireless devices. The LP3982 consumes less than 0.01μA in shutdown mode and has fast turn-on time less than 50μs. The other features include ultra low dropout voltage, high output accuracy, current limiting protection, and high ripple rejection ratio. Available in the 5-lead of SC-70 packages.

Features

◆ Ultra-Low-Noise for RF Application 　

◆ 2V- 6V Input Voltage Range

◆ Low Dropout : 220mV @ 300mA 　

◆ 1.2V, 1.5V, 1.8V, 2.5V, 2.8V 3.0V and 3.3V Fixed

◆ 300mA Output Current, 550A Peak Current

◆ High PSSR:-80dB at 1KHz ?

◆ <0.01uA Standby Current When Shutdown

◆ Available in SC-70-5 Package 　

◆ TTL-Logic-Controlled Shutdown Input 　

◆ Ultra-Fast Response in Line/Load transient 　

◆ Current Limiting and Thermal Shutdown Protection

◆ Quick start-up (typically 50uS)

Applications

◆ Portable Media Players/MP3 players

◆ Cellular and Smart mobile phone

◆ LCD

◆ DSC Sensor

◆ Wireless Card
