微源LDO稳压器 LP3993-36B3F 用于射频应用

General Description

The LP3993 is designed for portable applications with demanding performance and space requirements. The LP3993 performance is optimized for high voltage systems to deliver ultra low noise and low quiescent current. Regulator ground current increases only slightly in dropout, further prolonging the input system life.The LP3993 also works with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications, critical in hand-held wireless devices. The other features include ultra low dropout voltage, high output accuracy, current limiting protection, and high ripple rejection ratio.

Absolute Maximum Ratings

▲ Supply Input Voltage: -0.3V to 32V

▲ Other pin to GND: -0.3V to 8V

▲ Maximum Junction Temperature: 150°C

▲ Maximum Soldering Temperature (at leads, 10 sec): 260°C

▲ Operating Junction Temperature Range (Tj) : -40°C to 150°C

▲ Storage Temperature: -50°C to 125°C

Power Dissipation, PD @TA = 25°C

SOT23-3: 450mW

SOT89-3: 700mW

Package Thermal Resistance

SOT23-3, θJA: 250°C/W

SOT89-3, θJA: 165°C/W

ESD Susceptibility

HBM (Human Body Model): 2kV

MM(Machine-Model): 200V

Recommended Operating Conditions

▲ Supply Input Voltage: Vout+1V to 28V
