型号: | LP3995-33B5F |
厂 商: | |
品牌/商标: | 微源半导体 |
产品类别: | 集成电路/IC- DC/DC电源芯片 |
联系人: | 颜先生/William |
电话: | 0755-82170220,21001680 |
微源LDO稳压器 LP3995-33B5F 原装现货
General Description
The LP3995 is designed for portable applications with demanding performance and space requirements.
The LP3995 performance is optimized for high voltage systems to deliver ultra low noise and low quiescent current. Regulator ground current increases only slightly in dropout, further prolonging the input system life.
The LP3995 also works with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications, critical in hand-held wireless devices. The other features include ultra low dropout voltage, high output accuracy, current limiting protection, and high ripple rejection ratio.
Features
◆ Ultra-Low-Noise for RF Application
◆ Input Voltage up to35V
◆ Low Dropout : 600mV @ 100mA
◆ Output Current ≥200mA
◆ Ultra-Fast Response in Line/Load Transient
◆ Current Limiting and Thermal Shutdown
