PCT普诚 PT16103 480通道TFT LCD源极驱动器
DESCRIPTION
The PT16103 is a CMOS silicon source driver IC foractive matrix TFT LCD panels. After a CMOS/RSDS6-bit RGB data is applied, this device will generate64-gray scale for driving the TFT LCD panel sourcelines. It supports 480/402 channel selectable function,shift right/left selectable function, and cascade functionfor dot expansion.
FEATURES
● 64-gray scale source driver for active matrix TFTLCD panels
● Selectable 480/402 output channels
● Logic voltage power supply: 2.7V to 3.6V
● High voltage power supply: 7.0V to 13.5V
● Maximum RSDS operating frequency at 85 MHz
● Bi-directional shift right/left function
● COG package
