DESCRIPTION
The PT16106 is a CMOS silicon source driver IC foractive matrix TFT LCD panels. After a CMOS/RSDS 8-bit RGB data is applied, this device will generate 64-gray scale for driving the TFT LCD panel sourcelines. It supports 1440/1284/1278/1260/1200/1080/1026/1020/960/804/768 channel selectable function,shift right/left selectable function, and cascade functionfor dot expansion.
FEATURES
● 64-gray scale source driver for active matrix TFTLCD panels
● Selectable 1440/1284/1278/1260/1200/1080/1026/1020/960/804/768 output channels
● Logic voltage power supply: 2.7V to 3.6V
● High voltage power supply: 8.0V to 14.6V
● Maximum RSDS operating frequency at 85MHz
● Bi-directional shift right/left function
● COG package
