深圳供应 G509L10DT11G 致新电源开关芯片

Features

● 67mΩ High-Side MOSFET(G509xxxxT11G, G509x1SDTB1G)

● 120mΩ High-Side MOSFET(G509N02DT73G)

● 37mΩ High-Side MOSFET(G509x3xDxx1G)

● Available with 9 Versions of Current Limits with Fold-back.

● Operating Range:2.7V to 5.5V

● 2mS Typical Rise Time

● Fast Over Current Response 1.5μs (TYPICAL)

● Under Voltage Lockout

● 130μA Quiescent Supply Current

● 1μA Maximum Shutdown Supply Current

● Logic Level Enable Pin. Available with Active-High, Active-Low, or Enable Selection Versions

● No Reverse Current when Power Off

● Deglitched Open-Drain Over-Current Flag Output (OC )

● Available with or without Output Shutdown Pull-low Resistor

● Output Reverse Protection when Power ON

● G509xxxxT11G SOT-23-5 Package

● G509x25DTB1G SOT-23-6 Package

● G509N02DT73G SOT-23-3 Package

● G509x30DTO1G TSOT-23-5 Package

● G509xxxDTP1G TSOT-23-6 Package

● G509xxxDTR1G SOT-563 Package

● UL 2367 Recognition-File NO. E232223

● IEC 62368-1 Certified

Applications

● High-Side Power Protection Switch

● USB Power Management

● USB Host and Self-Powered Hubs

● USB Bus-Powered Hubs

● Hot Plug-In Power Supplies

● Battery-Charger Circuits
