CJ6206A33P 长晶科技 低压差稳压器

INTRODUCTION

The CJ6206 series are a group of positive voltage regulators manufactured by CMOS technologies with high ripple rejection, low power consumption and low dropout voltage, which can prolong battery life in portable electronics.The CJ6206 series work with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications. The CJ6206 series consume less than 0.1uA in shutdown mode and have fast turn-on time less than 50us.The series are very suitable for the battery-powered equipments, such as RF applications and other systems requiring a quiet voltage source.

Features

● Low Dropout Voltage：150mV@150mA

● Low Quiescent Current：5μA

● High Ripple Rejection：65dB@1kHz

● Excellent Line and Load Transient Response

● Operating Voltage：2.0V～7.0V

● Output Voltage：1.2 ~ 5.0V

● High Accuracy：±2％（Typ.）

● Built-in Current Limiter, Short-Circuit Protection

● TTL- Logic-Controlled Shutdown Input

Applications

● Cellular and Smart Phones

● Laptop, Palmtops and PDA

● Digital Still and Video Cameras

● MP3, MP4 Player

● Radio control systems

● Battery-Powered Equipment
